ROSON-3D with 200 kN pushing force
The ROSON-3D is A.P. van den Berg’s most powerful seabed Cone Penetration Testing (CPT) system. It is specifically engineered for accurate geotechnical soil investigations across a wide range of offshore environments, from nearshore locations to ultra-deepwater operations. Powered by the innovative ROSON Triple Drive and delivering an impressive pushing force of 200 kN, the ROSON-3D achieves maximum CPT performance with penetration depths of up to 80 meters, even at water depths of up to 4,000 meters. The system can be fully deployed from a vessel of opportunity, providing maximum flexibility for offshore projects.
ROSON-3D: maximum performance in deep waters
The ROSON-3D builds on A.P. van den Berg’s decades of experience in seabed CPT technology. Its advanced Triple Drive system clamps the CPT string between six electrically driven wheels and pushes it into the seabed in a fully controlled manner. Depending on seabed conditions, CPT penetration depths of up to 50 meters can be achieved. Like all ROSON seabed CPT systems, the ROSON-3D can be deployed from a vessel using an A-frame, crane, or moonpool, offering flexibility for a wide range of offshore operations.
Real-time data communication via Powerline
The ROSON-3D uses the Icone powerline system for data transmission through the umbilical, ensuring stable, real-time transfer of measurement data to the deck. In nearshore and shallow-water offshore conditions, the measuring cable can be routed directly from the cone to the deck. This allows direct connection to the Icontrol and eliminates the need for a cable reel in the mast, simplifying the setup and enabling longer CPT lengths.
Easy to operate
The ROSON-3D is designed for ease of operation and utilizes the Icone data acquisition system from A.P. van den Berg. It is fully compatible with all standard cone sizes (5 cm², 10 cm², and 15 cm²), including the deep water cone. The system can be expanded with a range of click-on modules, such as Seismic, Vane, Conductivity, and Magneto, providing flexibility for advanced geotechnical investigations.
Maximum CPT Performance Why the ROSON-3D?
- Up to 4,000 m water depth with 200 kN pushing force.
- 40 years of proven reliability.
- Accurate data output via the Icone data acquisition system.
- Easy operation and maintenance.
- Robust, low-maintenance construction.
- Flexible deployment from a vessel of opportunity.
Specifications ROSON-3D
| Feature | ROSON-3D |
| Dimensions (LxW) | 2.3 x 2.3 m or 3,5 x 3,5 m |
| Height | 3,7 m (min) – 4,6 m (max) |
| Max. pushing force | 200 kN |
| Surface pressure | 24 – 30 kPa |
| Weight (excl. ballast) | 9.800 kg |
| Dimensions winch (LxWxH) | 2,4 x 2,0 x 2,18 m |
Standard delivery
The ROSON-3D comes standard with:
-
Lifting frame
- Sheave block
-
Umbilical
-
Control box
- Winch (not supplied with the nearshore version – up to 500 m water depth)
Optional equipment
-
Guiding mast, available in lengths of 3.4, 6, and 10 m.
-
Various ballast options
- Seismic version
ROSON-3D in the spotlight
Which ROSON solution best fits your project?
A.P. van den Berg offers several ROSON variants, each tailored to a specific application. Choose the version that best suits your project objectives and water depth:
| Model | Max. pushing force | Application |
| ROSON-1D | 70 kN | Nearshore 500 m Offshore 1500 m |
| ROSON-2D | 140 kN | Nearshore 500 m Offshore 1500 m Deep Water 4000 m |
| ROSON-3D | 200 kN | Nearshore 500 m Offshore 1500 m Deep Water 4000 m |
Optional: Innovative SingleTwist Technology
The ROSON-2D and ROSON-3D are optionally available with the innovative SingleTwist technology. Compared to the standard ROSON, this technology increases the safety and efficiency of the CPT process by more than 30% and ensures reliable performance under demanding conditions.
Related CPT systems
Curious to find out whether the ROSON-3D is the right solution for your project? Contact us for personal advice, or explore our other CPTsystems, such as the ROSON-3D-ST or the WISON-APB wireline system.
